MacSync LWQS X2 LoRaWAN® Water pH Sensor Datasheet
Product Overview
MacSync LWQS X2 is an industrial-grade LoRaWAN® Water pH Sensor engineered for continuous online monitoring of water pH levels across drinking water systems, wastewater treatment plants (WWTP), sewage treatment plants (STP), industrial process water, cooling towers, reservoirs, rivers, lakes, borewells, aquaculture systems, and smart IoT water infrastructure.
Designed for high-accuracy and long-term deployment stability, the LoRaWAN Water pH Sensor continuously measures water acidity and alkalinity levels in real time, helping industries and utilities maintain water quality compliance, optimize chemical dosing, detect contamination risks, and monitor critical process conditions.
Built around a precision industrial electrochemical pH probe with advanced signal conditioning, MacSync LWQS X2 delivers stable and repeatable pH measurements with minimal sensor drift even in harsh outdoor and submerged monitoring environments. The rugged industrial enclosure and IP-rated sensing architecture make the device ideal for industrial water quality monitoring applications requiring reliable long-term field performance.
Optimized for ultra-low-power operation and long-range wireless telemetry, the sensor securely transmits pH and water quality data over LoRaWAN® networks, enabling multi-year battery-powered operation for remote and unmanned deployments. The device supports real-time cloud monitoring, threshold-based alerts, predictive maintenance analytics, and centralized IoT-based water management systems.
With support for LoRaWAN® v1.0.4, AES-encrypted wireless communication, OTA configuration using the Macnman Maya App, and compatibility with ChirpStack, TTN, MQTT, Orbiwise, LORIOT, and private LoRaWAN® infrastructures, MacSync LWQS X2 provides a scalable and future-ready solution for wireless water quality monitoring and industrial water pH analytics.
Download Center
Download the PDF version of the datasheet.
Click here to view the decoders for MacSync LWQS X2
Key Features
Industrial LoRaWAN® Water pH Sensor Advanced industrial-grade LoRaWAN® Water pH Sensor engineered for continuous online water quality monitoring across industrial, municipal, environmental, and smart IoT infrastructure.
High-Accuracy Online Water pH Monitoring Precision electrochemical pH sensing technology designed for stable and repeatable real-time pH monitoring in drinking water, wastewater, STP, WWTP, and industrial process applications.
Real-Time Wireless Water Quality Analytics Continuous LoRaWAN® water quality monitoring with real-time pH telemetry for smart water infrastructure, environmental monitoring, and industrial automation deployments.
Long-Range LoRaWAN® Connectivity Ultra-low-power long-range LoRaWAN® communication for remote water pH monitoring deployments across cities, industrial facilities, reservoirs, rivers, lakes, and distributed utility infrastructure.
Designed for Harsh Water Environments Rugged IP-rated industrial enclosure and corrosion-resistant pH probe engineered for submerged, outdoor, wastewater, and chemically aggressive environments.
Low Drift & Long-Term Stability Industrial signal conditioning and precision pH sensing architecture ensure low sensor drift and long-term monitoring stability in continuous deployments.
Threshold-Based Water Quality Alerts Intelligent threshold-based event reporting for abnormal pH variation, contamination detection, chemical imbalance alerts, and industrial process anomaly monitoring.
Multi-Year Battery Powered Operation Optimized ultra-low-power design enables long-term battery-powered deployment for unmanned and remote IoT water quality monitoring applications.
BLE Configuration via Maya App Simplified local configuration, diagnostics, commissioning, firmware management, and device tuning using the Macnman Maya Android App.
Compatible with Major LoRaWAN® Platforms Seamless integration with ChirpStack, TTN, MQTT, LORIOT, Orbiwise, SCADA systems, cloud dashboards, and private industrial LoRaWAN® infrastructures.
Suited Applications
Drinking Water Quality Monitoring Continuous LoRaWAN® water pH monitoring for municipal drinking water systems, overhead tanks, underground reservoirs, water treatment plants, and smart utility infrastructure.
Industrial Water pH Monitoring Real-time industrial water quality monitoring for process water systems, manufacturing facilities, industrial automation, and chemical processing applications.
Sewage Treatment Plant (STP) Monitoring Online LoRaWAN® pH sensor deployments for sewage treatment plants to monitor chemical balance, biological treatment efficiency, and wastewater process optimization.
Wastewater Treatment Plant (WWTP) Analytics Industrial wastewater pH monitoring for influent and effluent streams to support environmental compliance and discharge quality analysis.
Industrial Effluent Monitoring Wireless water pH monitoring for industrial discharge systems to identify abnormal contamination, chemical leakage, acidic discharge, and process anomalies.
Cooling Tower Water Quality Monitoring Continuous pH analytics for cooling towers and circulating water systems to prevent corrosion, scaling, and chemical imbalance in industrial infrastructure.
Aquaculture & Fish Farming Monitoring Real-time pH monitoring for aquaculture ponds, fish farming infrastructure, hatcheries, and aquatic ecosystem management applications.
River, Lake & Reservoir Water Monitoring Long-range LoRaWAN® water quality monitoring for environmental analysis, pollution tracking, ecosystem protection, and smart water resource management.
Smart City & IoT Water Infrastructure Integrated IoT water quality monitoring solution for smart cities, utility telemetry, remote environmental analytics, and centralized cloud-based monitoring platforms.
Borewell & Groundwater Quality Monitoring Continuous groundwater pH monitoring for borewells, underground water reserves, agricultural water systems, and rural utility infrastructure.
Technical Specifications
MacSync LWQS X2 Variants
| SKU | Variant Name | Power Source | Communication | Ideal For |
|---|---|---|---|---|
| 8904 | MacSync-L-WQPH-BS-X1 | Battery (19 Ah) | LoRaWAN® | Remote water pH monitoring for drinking water systems, reservoirs, rivers, lakes, borewells, STP, WWTP, and industrial water quality applications |
| 8905 | MacSync-L-WQPH-PS-X1 | 9–36 V DC | LoRaWAN® | Continuous industrial water pH monitoring for process water, cooling towers, chemical dosing systems, and wastewater treatment plants |
| 8906 | MacSync-M-WQPH-BS-X1 | Battery (19 Ah) | MacTalk | Battery-operated MacTalk deployments for remote water pH monitoring and environmental water quality applications |
| 8907 | MacSync-M-WQPH-PS-X1 | 9–36 V DC | MacTalk | MacTalk-based industrial water pH monitoring with continuous external power for process automation |
| 8908 | MacSync-B-WQPH-BS-X1 | Battery (19 Ah) | BLE | Local water pH monitoring, commissioning, calibration, and diagnostics using BLE connectivity |
What's in the Box?
Make sure the package contains the following items before installation and deployment of the LoRaWAN® Water pH Sensor.
- MacSync LWQS X2 LoRaWAN Water pH Sensor
- Industrial pH Probe
- Industrial Mounting Bracket *
- User Manual
- Warranty Card
- IP68 Cable Extender *
- Mounting Screws & Installation Hardware
- Power Adapter *
Accessories marked with (*) must be purchased separately and may not be included in the package.
MacSync LWQS X2 Dimensions
The MacSync LWQS X2 LoRaWAN Water pH Sensor features a rugged industrial-grade enclosure engineered for long-term industrial and outdoor water quality monitoring deployments. With compact dimensions of 152 mm × 62 mm × 43 mm, the device enables flexible installation across drinking water systems, wastewater treatment plants (WWTP), sewage treatment plants (STP), industrial process water systems, reservoirs, borewells, cooling towers, rivers, lakes, aquaculture systems, and smart IoT water infrastructure.
Its compact low-profile design simplifies wall mounting and industrial installation while maintaining reliable pH monitoring performance in harsh operating environments including high humidity, water exposure, industrial contamination, chemical environments, dust, and extreme outdoor temperatures.
Frequently Asked Questions
What is the MacSync LWQS X2 used for?
MacSync LWQS X2 is an industrial LoRaWAN water pH sensor for online pH monitoring in drinking water, wastewater treatment, STP, WWTP and effluent. Typical applications include Drinking Water Quality Monitoring, Industrial Water pH Monitoring, Sewage Treatment Plant (STP) Monitoring, Wastewater Treatment Plant (WWTP) Analytics, Industrial Effluent Monitoring and Cooling Tower Water Quality Monitoring.
What does the MacSync LWQS X2 measure, and how accurately?
Measurement specifications of the MacSync LWQS X2:
- pH: range 0 to 14 pH, accuracy ±0.1 pH, resolution 0.01 pH.
Which LoRaWAN frequency bands and network servers does the MacSync LWQS X2 support?
The MacSync LWQS X2 supports LoRaWAN® (v1.0.4) and the Macnman MacTalk Protocol on the IN865 / RU864 / EU868 / US915 / AU915 / KR920 / AS923 frequency bands. It joins the network by OTAA activation. It runs as Class A by default and can be set to Class C in the Maya app. Supported network servers: Private LNS, ChirpStack, TTN, MQTT, Orbiwise, Netmore, and on-premise industrial IoT deployments.
How long does the MacSync LWQS X2 battery last?
The battery-operated MacSync LWQS X2 runs on a 19 Ah industrial-grade Li-SOCl₂ cell. Estimated battery life is ~2 years at a 5-minute reporting interval, ~4 years at a 15-minute reporting interval and ~7+ years at a 60-minute reporting interval. A solar option adds a 20 W High-Efficiency Solar Panel with an Integrated 8000 mAh Solar Rechargeable Battery.
What is the IP rating and operating temperature of the MacSync LWQS X2?
The MacSync LWQS X2 has an ingress protection rating of IP65 standard (IP67 optional variant) and an operating temperature range of -40°C to +80°C. Operating humidity: 0% ~ 100% RH (non-condensing). Mounting options: Pole Mount / Wall Mount.
How is the MacSync LWQS X2 configured?
The MacSync LWQS X2 is configured with the Macnman Maya Android app over Bluetooth Low Energy (BLE). Settings can also be changed remotely with over-the-air downlink commands.
What is included in the box with the MacSync LWQS X2?
The box contains: MacSync LWQS X2 LoRaWAN Water pH Sensor, Industrial pH Probe, User Manual, Warranty Card and Mounting Screws & Installation Hardware. Industrial Mounting Bracket, IP68 Cable Extender and Power Adapter are optional and may need to be purchased separately.
