MacSync-L-Odor-X1 Datasheet
Product Overview
MacSync-L-Odor-X1 is a qualitative LoRaWAN® odor monitoring sensor designed to detect, track, and trend odor intensity levels in industrial, municipal, and outdoor environments. Instead of measuring individual gas concentrations in ppm, the device evaluates overall odor presence and strength, making it ideal for applications where nuisance odor detection, early warning, and compliance monitoring are critical.
Built on advanced sensing elements and intelligent signal processing, MacSync-L-Odor-X1 converts complex odor signatures into a simple odor index / odor level, enabling easy interpretation and actionable insights. This qualitative approach allows operators to identify odor spikes, persistent odor patterns, and abnormal events without requiring gas-specific calibration or complex analysis.
Engineered for long-term field deployment, the device features an ultra‑low‑power LoRaWAN® Class A architecture, ensuring multi‑year battery life even in remote or unmanned locations. Its rugged, ingress‑protected enclosure makes it suitable for harsh environments such as sewage treatment plants (STP), wastewater facilities (WWTP), landfills, waste processing units, factories, and smart city infrastructure.
With support for LoRaWAN® v1.0.4, AES‑encrypted communication, wide regional frequency bands, and optional BLE‑based configuration via the Maya App, MacSync-L-Odor-X1 enables fast deployment, remote monitoring, and scalable fleet management across public or private LoRaWAN® networks.
Whether used for regulatory reporting, community odor complaint management, or proactive operational control, MacSync-L-Odor-X1 delivers a reliable, low‑maintenance, and future‑ready odor monitoring solution—transforming subjective smell complaints into measurable, data‑driven intelligence.
 |  |
|---|---|
 |  |
Download Center
Download the PDF Version of the Datasheet .
Click here to view the decoders for MacSync-L-Odor-X1
Key Features
Qualitative Odor Intensity Detection Measures overall odor presence and strength using a qualitative odor index, ideal for nuisance odor monitoring without ppm-level gas complexity.
Odor Index & Trend Analysis Converts complex odor signatures into a simple odor level, enabling long-term trend analysis and easy correlation with operational events.
Early Warning & Threshold Alerts Configurable odor thresholds trigger alerts for sudden odor spikes, persistent odor conditions, and abnormal events.
Ultra‑Low Power LoRaWAN® Operation LoRaWAN® Class A architecture ensures multi-year battery life for continuous odor monitoring in remote and unmanned locations.
Designed for Outdoor & Harsh Environments Rugged, ingress-protected enclosure suitable for STP, WWTP, landfills, waste processing plants, and industrial sites.
No Gas‑Specific Calibration Required Qualitative sensing eliminates the need for individual gas calibration, reducing maintenance effort and operational complexity.
Secure Long‑Range Wireless Communication AES-encrypted LoRaWAN® communication enables reliable long-range data transmission over public or private networks.
Flexible Uplink & Reporting Modes Supports time-based, threshold-based, and event-driven uplinks to optimize data usage and battery performance.
BLE Configuration via Maya App Local device configuration, diagnostics, and OTA updates using the Macnman Maya mobile application.
Scalable & Network-Agnostic Compatible with all major public and private LoRaWAN® network servers for large-scale odor monitoring deployments.
Suited Applications
Sewage Treatment Plants (STP) Continuous monitoring of nuisance odors from inlet chambers, aeration tanks, and sludge handling areas to support compliance and reduce public complaints.
Wastewater Treatment Plants (WWTP) Odor intensity tracking across treatment processes to detect abnormal events, process inefficiencies, and odor spikes.
Landfills & Waste Disposal Sites Early detection and trend analysis of odor emissions to manage landfill gas impact and community exposure.
Solid Waste & Composting Facilities Qualitative odor monitoring to identify high-odor zones and optimize waste handling and composting operations.
Industrial Manufacturing Plants Odor monitoring around chemical processing, food processing, paper mills, and industrial production areas.
Smart City Odor Monitoring City-wide deployment for monitoring odor nuisance in residential zones, industrial belts, and public infrastructure.
Environmental Compliance & Reporting Supports regulatory monitoring programs and data-driven reporting for odor-related compliance requirements.
Community Odor Complaint Management Objective odor data to correlate citizen complaints with real odor events and operational conditions.
Remote & Unmanned Locations Long-range LoRaWAN® connectivity enables odor monitoring at isolated sites without continuous human presence.
Technical Specification
General
Specifications
Part Order Number
MacSync-L-Odor-X1
Product Brand
Macnman Technologies Pvt Ltd
Temperature
Measurement
Range
-30°C to +70°C
Accuracy
0°C to +70°C: ±0.3°C & -30°C to 0°C: ±0.6°C
Resolution
0.1°C
Calibration
Factory calibrated
Probe Options
Internal & External Both Options
Humidity
Measurement
Range
0% to 100% RH
Accuracy
10% to 90% RH: ±3% RH & <10% or >90% RH: ±5% RH
Resolution
0.5% RH
Calibration
Factory calibrated
Pressure
Measurement
Range
300 hPa to 1100 hPa
Accuracy
±1.0 hPa (typical at 25°C, 300–1100 hPa)
Resolution
0.1 hPa
Long‑Term Stability
≤ ±1 hPa/year
Calibration
Factory calibrated
NH3
Measurement
Gas Detected
Ammonia (NH₃)
Detection Range
1 to 300 ppm
Sensitivity
R₀ (in air) / Rs (in 50 ppm NH₃) ≥ 3
Measurement Type
Gas concentration (ppm)
Operating Temperature
-10°C to +50°C
Operating Humidity
15% to 90% RH (non-condensing)
Expected Lifespan
≥ 5 years (in air)
Calibration
Factory calibrated
H2S
Measurement
Gas Detected
Hydrogen Sulfide (H₂S), Benzene
Detection Range
0.5 to 50 ppm
Sensitivity
R₀ (in air) / Rs (in 50 ppm H₂S) ≥ 3
Measurement Type
Gas concentration (ppm)
Operating Temperature
-10°C to +50°C
Operating Humidity
15% to 90% RH (non-condensing)
Expected Lifespan
≥ 5 years (in air)
Calibration
Factory calibrated
Wireless
Transmission
Wireless Protocols
LoRaWAN® (v1.0.4)
Macnman MacTalk Protocol
Antenna
Internal high-efficiency antenna
Supported Bands
IN865 / RU864 / EU868 / US915 / AU915 / KR920 / AS923-1/2/3/4
Tx Power
26 dBm @ 868 MHz / 20 dBm @ 915 MHz / 19 dBm @ 470 MHz
Sensitivity
-137 dBm @ 300 bps
Activation
OTAA
LoRaWAN® Class
Class A (default)
Configurable to Class C via Maya
LED
Status
LED Type
1 Internal Multi-Color LED
Solid Blue
Device is connected with Maya App
Flashing Blue
OTA (Over-the-Air) update in progress
Slow Blinking Green
Attempting to connect to the LoRaWAN® network
Single Red Blink
A confirmed parameter of MacSync is being modified
Device
Configuration
Configuration
Via Macnman Maya Android App
Uplink Modes
Time Based / Threshold Based / Sampling Based
Stored Records*
30,000 Records
Remote Configuration
JSON Format Data - from server
Battery
Performance
Battery Type
Li-SOCl₂ Cell (19Ah) Industrial grade
Power Consumption
~100 µA in sleep mode
~50 mA during transmission
Battery Life
Up to 10 years (10 Mins Uplink Interval)
Supported
LNS
Supports Major LNS
Private LNS
Chirpstack
The Things Networks
MQTT
Orbiwise
LORIOT
Direct PLC On-Prim Installations
Physical
Characteristics
Power Supply(Optional)
9-36 V DC
Operating Temperature
-40°C to +80°C
Humidity Range
0% to 100% RH (non-condensing)
Ingress Protection
IP65 standard (IP67 optional variant)
Housing Material
Glass field Nylon
Color
Matte White
Weight
~110g
Mounting Options
Pole Mounting / Wall Mounting
Electrical
Characteristics
Input Voltage Range (Optional Varient)
9-36 V DC (External Supply)
Power Consumption
~100 µA in sleep mode
~50 mA during transmission
Input Impedance
>10 MΩ for voltage inputs
Communication
Options
BLE Connectivity
For local configuration and diagnostics via Maya App
Cloud Protocols
MQTT / HTTPS / TCP IP (Gateway Dependent )
Serial Interface
RS485 Modbus RTU support (optional)
Certifications &
Compliance
WPC
Compliant
RoHS
Conforms to RoHS directive
Security &
Encryption
Data Encryption
AES-256 end-to-end encryption
Authentication
OTAA activation modes
Firmware Protection
Secure boot and signed OTA updates
MacSync-L-Odor-X1 Variants
| Variant Name | Power Source | Battery Capacity | Solar Support | External Flash | Ideal For |
|---|---|---|---|---|---|
| MacSync-L-Odor-X1-BO | Battery | 19 Ah | ✖️ | ✔️ | Remote or portable deployments with low power |
What's in the box ?
Make sure box contains following items before installations
Accessories must be purchased separately & may not be included in the box.
Product Dimensions
