MacSync Wi-Fi 7-in-1 Soil Sensor Technical Specifications
Versions
Technology
General Specifications
- Part Order Number
- Wi-Fi 7-in-1 soil sensor, battery variant (part number on request)
- Product Brand
- Macnman Technologies Pvt Ltd
Interfaces
- 7-in-1Soil Probe: Moisture, Temperature, EC, pH, N, P, K
Wireless Coverage
2.4/5GHz
BLE
Wi-Fi coverage depends on access-point placement and on what stands between the access point and the transmitter. If the connection drops, the sensor stores up to 30,000 records on-board and syncs when the link returns.
Cloud Platforms
MacSync Wi-Fi 7-in-1 Dimensions
What's in the Box?
- MacSync Wi-Fi 7-in-1 Soil Sensor
- Mounting Clip
- Mounting Screws
- User Manual
- Warranty Card
- IP68 Cable Extender (optional)
(*) Accessories need to be purchased separately and are not included in the box.
Soil Moisture & Temperature
- Moisture Range
- 0% to 100% VWC
- Moisture Accuracy
- ±5%
- Moisture Resolution
- 0.1%
- Moisture Repeatability
- ±1%
- Temperature Range
- -45 °C to +115 °C
- Temperature Accuracy
- ±0.5 °C
- Temperature Resolution
- 0.1 °C
- Temperature Repeatability
- ±0.2 °C
EC & pH
- EC Range
- 0 to 10,000 µS/cm
- EC Accuracy
- ±3% of full scale
- EC Resolution
- 10 µS/cm
- EC Repeatability
- ±1% of full scale
- pH Range
- 3 to 9 pH
- pH Accuracy
- ±0.3 pH
- pH Resolution
- 0.1 pH
- pH Repeatability
- ±0.1 pH
NPK (Estimated)
- Parameters
- Nitrogen (N), Phosphorus (P), Potassium (K)
- Range
- 0 to 1,999 mg/kg each
- Accuracy
- ±2% of full scale
- Resolution
- 1 mg/kg
- Repeatability
- ±1% of full scale
- Use
- Trend estimation, Check against a laboratory soil test
Soil Probe
- Electrodes
- Corrosion-resistant stainless steel
- Suitable Soils
- Clay, Sandy, Saline, Wet and high-moisture
- Cable Accessory
- IP68 cable extender (optional)
Wi-Fi Connectivity
- Wi-Fi Standards
- IEEE 802.11 b/g/n/ac
- Frequency Bands
- 2.4 GHz and 5 GHz (dual-band)
- Operating Modes
- Station (client), Access point (configuration)
- Wi-Fi Security
- WPA2-PSK, WPA3
- IP Configuration
- DHCP, Static IP
- Typical Indoor Range
- Up to 100 m (environment dependent)
Protocols & Cloud
- Network Protocols
- MQTT, HTTP, HTTPS
- Cloud Platforms
- AWS IoT Core, Microsoft Azure IoT Hub, Google Cloud (via MQTT / HTTPS), Custom IoT platforms
- Integration
- MQTT brokers, REST / HTTPS APIs, Webhooks, SCADA and BMS
- Deployment
- On-premise servers, Private cloud, Public cloud
Logging & Reporting
- Uplink Modes
- Time based, Threshold based, Sampling based
- Threshold Alerts
- Low and high limits on measured values
- Stored Records
- 30,000 records
- Remote Configuration
- JSON commands from the server
Power
- Battery
- 19 Ah cell
- Power Consumption
- ~100 µA sleep, ~150 mA during transmission
- Estimated Battery Life
- About 2.5 years at 15-minute uploads, About 4.3 years at 30-minute uploads, About 6.7 years at hourly uploads, 19 Ah cell, DHCP, TLS — calculator estimate
Device Management
- Configuration
- Macnman Maya Android App
- Local Configuration
- BLE-based via Maya
- Status LED
- 1 × internal multi-color LED
Physical Characteristics
- Operating Temperature
- -40 °C to +80 °C (transmitter)
- Humidity Range
- 0% to 100% RH (non-condensing)
- Ingress Protection
- IP65 standard, IP67 optional variant
- Housing
- Glass-filled nylon, matte white
- Mounting
- Pole mount, Wall mount
Security & Encryption
- Transport Security
- TLS / SSL encrypted communication
- Data Encryption
- AES-256
- Firmware Protection
- Secure boot, Signed OTA updates
Certifications & Compliance
- WPC
- Compliant
- RoHS
- Conforms to RoHS directive
